Davis, et. al., Atlas to Accompany the Official Records of the Union and Confederate Armies, plate CLXXIII.

Wikipedia says: Field carriages… were designed to allow guns to be deployed on the battlefield and were provided with a pair of large wheels similar to those used on carts or wagons. The cheeks of field carriages were much narrower than those on the naval carriage and the rear end, called a “trail”, rested on the ground. When the gun needed to be moved any distance, the trail could be lifted onto a second separate axle called a limber, which could then be towed by a team of horses or oxen. Limbers had been invented in France in about 1550. An innovation from the mid-18th century was the invention of the “block trail”, which replaced the heavy cheeks and transoms of the “double-bracket” carriage with a single wooden spar reinforced with iron.
